mi::neuraylib::ILight Class Reference

[Leaf nodes]

Description

Point, spot, directional and area lighting. All lights are positioned at the origin of the local light space and point down the negative z -axis, like the camera. This differs from some traditional scene description formats, in which a light can have an origin, a direction, and possibly other orientation vectors. Instead, uses transformations to express these properties.

Spot lights are modeled by using the spot_edf distribution function on a point light.

For directional lights, the (transformed) position is irrelevant. The traditional use of a directional light is as an approximation of the rays of the sun, which is at such a great distance to the earth that at human scale the light rays are effectively parallel.

In addition, provides the ability to specify an emission distribution function in a material. In this way, any object can be a source of light emission, but may also have reflective and transmissive properties as well.

See also [:ipmlink environment_dome_and_implicit_groundplane Environment dome and implicit groundplane].

See also:

mi::neuraylib::Light_type, mi::neuraylib::Light_area_shape

Public Member Functions

virtual Float64 get_area_radius() const =0
Returns the radius of the area for area lights. More...
virtual Light_area_shape get_area_shape() const =0
Returns the area light shape.
virtual Float64 get_area_size_x() const =0
Returns the size of the area in x direction for area lights. More...
virtual Float64 get_area_size_y() const =0
Returns the size of the area in y direction for area lights. More...
virtual Light_type get_type() const =0
Returns the light type.
virtual void set_area_radius( Float64 radius) =0
Sets the radius of the area for area lights. More...
virtual void set_area_shape( Light_area_shape light_area_shape) =0
Sets the area light shape.
virtual void set_area_size_x( Float64 size_x) =0
Sets the size of the area in x direction for area lights. More...
virtual void set_area_size_y( Float64 size_y) =0
Sets the size of the area in y direction for area light types. More...
virtual void set_type( Light_type type) =0
Sets the light type.

Member Functions

virtual Float64 mi::​neuraylib::​ILight::get_area_radius() const [pure virtual]

Returns the radius of the area for area lights. This value is only meaningful for lights of type mi::neuraylib::AREA_DISC, mi::neuraylib::AREA_SPHERE, and mi::neuraylib::AREA_CYLINDER.

virtual Light_area_shape mi::​neuraylib::​ILight::get_area_shape() const [pure virtual]

Returns the area light shape.

virtual Float64 mi::​neuraylib::​ILight::get_area_size_x() const [pure virtual]

Returns the size of the area in x direction for area lights. This value is only meaningful for lights of type mi::neuraylib::AREA_RECTANGLE and mi::neuraylib::AREA_CYLINDER. For cylindrical area lights, this value is half of the height of the cylinder.

virtual Float64 mi::​neuraylib::​ILight::get_area_size_y() const [pure virtual]

Returns the size of the area in y direction for area lights. This value is only meaningful for lights of type mi::neuraylib::AREA_RECTANGLE.

virtual Light_type mi::​neuraylib::​ILight::get_type() const [pure virtual]

Returns the light type.

virtual void mi::​neuraylib::​ILight::set_area_radius( Float64 radius) [pure virtual]

Sets the radius of the area for area lights. This value is only meaningful for lights of type mi::neuraylib::AREA_DISC, mi::neuraylib::AREA_SPHERE, and mi::neuraylib::AREA_CYLINDER.

virtual void mi::​neuraylib::​ILight::set_area_shape( Light_area_shape light_area_shape) [pure virtual]

Sets the area light shape.

virtual void mi::​neuraylib::​ILight::set_area_size_x( Float64 size_x) [pure virtual]

Sets the size of the area in x direction for area lights. This value is only meaningful for lights of type mi::neuraylib::AREA_RECTANGLE and mi::neuraylib::AREA_CYLINDER. For cylindrical area lights, this value is half of the height of the cylinder.

virtual void mi::​neuraylib::​ILight::set_area_size_y( Float64 size_y) [pure virtual]

Sets the size of the area in y direction for area light types. This value is only meaningful for lights of type mi::neuraylib::AREA_RECTANGLE.

virtual void mi::​neuraylib::​ILight::set_type( Light_type type) [pure virtual]

Sets the light type.
