This interface represents a pixel image file. More...
Public Member Functions | |
| virtual Sint32 | reset_file (const char *filename)=0 |
Resets the underlying file to a new file given by filename. More... |
|
| virtual const char * | get_filename () const =0 |
| Returns the resolved file name of the file containing the image. More... |
|
| virtual const char * | get_original_filename () const =0 |
| Returns the unresolved file as passed to reset_file(). More... |
|
| virtual bool | set_from_canvas (const neuraylib::ICanvas *canvas)=0 |
| Sets the pixels of this image based on the passed canvas (without sharing). More... |
|
| virtual bool | set_from_canvas (neuraylib::ICanvas *canvas, bool shared=false)=0 |
| Sets the pixels of this image based on the passed canvas (possibly sharing the pixel data). More... |
|
| virtual const neuraylib::ICanvas * | get_canvas (Uint32 level=0) const =0 |
| Returns a canvas with the pixel data of the image. More... |
|
| virtual const char * | get_type () const =0 |
| Returns the pixel type of the image. More... |
|
| virtual Uint32 | get_levels () const =0 |
| Returns the number of levels in the mipmap pyramid. More... |
|
| virtual Uint32 | resolution_x (Uint32 level=0) const =0 |
| Returns the horizontal resolution of the image. More... |
|
| virtual Uint32 | resolution_y (Uint32 level=0) const =0 |
| Returns the vertical resolution of the image. More... |
|
| virtual Uint32 | resolution_z (Uint32 level=0) const =0 |
| Returns the number of layers of the 3D image. More... |
|
Additional Inherited Members | |
 Public Types inherited from mi::base::Interface_declare< 0xca59b977, 0x30ee, 0x4172, 0x91, 0x53, 0xb7, 0x70, 0x2c, 0x6b, 0x3a, 0x76, IScene_element >
| |
| typedef Interface_declare< id1, id2, id3, id4, id5, id6, id7, id8, id9, id10, id11, IScene_element > |
Self |
| Own type. More... |
|
| typedef Uuid_t< id1, id2, id3, id4, id5, id6, id7, id8, id9, id10, id11 > |
IID |
| Declares the interface ID (IID) of this interface. More... |
|
|
Static Public Member Functions inherited from mi::base::Interface_declare< 0xca59b977, 0x30ee, 0x4172, 0x91, 0x53, 0xb7, 0x70, 0x2c, 0x6b, 0x3a, 0x76, IScene_element >
| |
| static bool | compare_iid (const Uuid &iid) |
Compares the interface ID iid against the interface ID of this interface and of its ancestors. More... |
|
This interface represents a pixel image file.
It supports different pixel types, 2D and 3D image data, and mipmap levels. Its main usage is in textures, see the mi::ITexture class.
The image coordinate system has its origin in the lower left corner in the case of 2D image data.
Note that editing an existing image has unusual semantics that differ from all other DB elements. Usually, when editing a database element, an identical copy of the database element is created (the existing one cannot be used because it might be needed for other transactions, other scopes, or in case the transaction is aborted). For images, this implies a copy of all the pixel data which is very expensive.
There are only two mutable methods on this interface, reset_file() and set_from_canvas(); all other methods are const. Both methods eventually replace the entire pixel data anyway. Therefore, when an image is edited, the pixel data is not copied, but replaced by a dummy image of size 1x1. This approach saves the unneeded, but expensive copy of the original pixel data. When afterwards one of two methods above is called, the image uses the correct pixel data again.
Note that this also affects the results from methods like resolution_x(), etc. (if you want to know the resolution of an existing image without changing it, you should access the image, not edit it). Furthermore, you might end up with the dummy image if you do not call reset_file() or set_from_canvas() (or if these methods fail).
|
pure virtual |
Returns a canvas with the pixel data of the image.
Note that it is not possible to manipulate the pixel data.
| level | The desired mipmap level. Level 0 is the highest resolution. |
NULL in case of failure.
|
pure virtual |
Returns the resolved file name of the file containing the image.
The method returns NULL if there is no file associated with the image, e.g., after default construction, calls to set_from_canvas(), or failures to resolve the file name passed to reset_file().
|
pure virtual |
Returns the number of levels in the mipmap pyramid.
|
pure virtual |
Returns the unresolved file as passed to reset_file().
The method returns NULL after default construction or calls to set_from_canvas().
|
pure virtual |
Returns the pixel type of the image.
See Types for a list of supported pixel types.
|
pure virtual |
Resets the underlying file to a new file given by filename.
Note that support for a given image format requires an image plugin capable of handling that format.
NULL pointer).Returns the horizontal resolution of the image.
| level | The desired mipmap level. Level 0 is the highest resolution. |
Returns the vertical resolution of the image.
| level | The desired mipmap level. Level 0 is the highest resolution. |
Returns the number of layers of the 3D image.
| level | The desired mipmap level. Level 0 is the highest resolution. |
|
pure virtual |
Sets the pixels of this image based on the passed canvas (without sharing).
| canvas | The pixel data to be used by this image. Note that the pixel data is copied, not shared. If sharing is intended use mi::IImage::set_from_canvas(mi::neuraylib::ICanvas*,bool) instead. |
true if the pixel data of this image has been set correctly, and false otherwise.
|
pure virtual |
Sets the pixels of this image based on the passed canvas (possibly sharing the pixel data).
| canvas | The pixel data to be used by this image. |
| shared | If false (the default), the pixel data is copied from canvas and the method does the same as mi::IImage::set_from_canvas(const mi::neuraylib::ICanvas*). If set to true, the image uses the canvas directly (doing reference counting on the canvas pointer). You must not modify the canvas content after this call. |
true if the pixel data of this image has been set correctly, and false otherwise.
