Abstract interface for isotropic BSDF data. More...
Public Member Functions | |
virtual Uint32 | get_resolution_theta () const =0 |
Returns the number of values in theta direction. More... |
|
virtual Uint32 | get_resolution_phi () const =0 |
Returns the number of values in phi direction. More... |
|
virtual Bsdf_type | get_type () const =0 |
Returns the type of the values. More... |
|
virtual const IBsdf_buffer * | get_bsdf_buffer () const =0 |
Returns the buffer containing the actual values. More... |
|
Additional Inherited Members | |
Public Types inherited from mi::base::Interface_declare< 0x23fd6d83, 0x057b, 0x4507, 0xb4, 0x93, 0x0e, 0xbd, 0x44, 0x7b, 0x07, 0xb9 > | |
typedef Interface_declare< id1, id2, id3, id4, id5, id6, id7, id8, id9, id10, id11, IInterface > |
Self |
Own type. More... |
|
typedef Uuid_t< id1, id2, id3, id4, id5, id6, id7, id8, id9, id10, id11 > |
IID |
Declares the interface ID (IID) of this interface. More... |
|
Static Public Member Functions inherited from mi::base::Interface_declare< 0x23fd6d83, 0x057b, 0x4507, 0xb4, 0x93, 0x0e, 0xbd, 0x44, 0x7b, 0x07, 0xb9 > | |
static bool | compare_iid (const Uuid &iid) |
Compares the interface ID iid against the interface ID of this interface and of its ancestors. More... |
|
Abstract interface for isotropic BSDF data.
The isotropic BSDF data is modeled as a three-dimensional grid of values. The three dimensions of the grid are called theta_in
, theta_out
, and phi_in
. The values can be of two types: scalars or RGB values (see Bsdf_type). The grid values are uniformly distributed in the range [0,pi/2) for theta_in
and theta_out
and in the range [0,pi] for phi_in
. The resolution, i.e., the number of values, of each dimension is arbitrary with the limitation that the resolution for theta_in
and theta_out
has to be identical.
|
pure virtual |
Returns the buffer containing the actual values.
Implemented in mi::Bsdf_isotropic_data.
|
pure virtual |
Returns the number of values in phi direction.
Implemented in mi::Bsdf_isotropic_data.
|
pure virtual |
Returns the number of values in theta direction.
Implemented in mi::Bsdf_isotropic_data.
|
pure virtual |
Returns the type of the values.
Implemented in mi::Bsdf_isotropic_data.
